- 94.
×
LG PREMTB10U Programmable Thermostat Instruction Manual
OPERATION INSTRUCTION
51
Different mode drive (This is not a US feature.)
Different mode drive is a phenomenon taking place when indoor units' drive mode is different in
the case that a few indoor units are set up at one AHU.
Note: Different mode drive is not available for cooling-only models
While a few indoor units are running
1
cooling on a heat pump system, it
doesn’t operate heating drive if any
indoor unit operates heating drive.
While a few indoor units are running
heating on a heat pump system, it does
not run if any indoor unit runs cooling or
dehumidification.
2
It is the indication that it is operating
heating drive on a heat pump system.
By pressing
button,
3
indoor unit automatically runs
at the mode that different
indoor units are running after
about 5 seconds and
operates.
| General | Details |
|---|---|
| Name | LG PREMTB10U Programmable Thermostat Instruction Manual |
| Make | LG |
| Language | English |
| Filetype | PDF (Download) |
| File size | 4.55 MB |
(1 votes, average: 5.00 out of 5)
