Innova B3V151 Electronic Thermostat User Manual
UnIT WITH TOUCHpAD COD. ECA844 - EWA844
3ꢀ4 Warnings
3ꢀ4ꢀ1 Operating the unit if the remote
control is not available
If you lose the remote control, the batteries run out or the
remote stops working, you can be operate the device with
the keys on the touch-screen display on-board the ma-
chine.
3ꢀ4ꢀ2 Troubleshooting
For the user it is important to distinguish any malfunction
or performance levels that differ from the system’s stand-
ard operating values (see technical specifications). The
most common problems can be easily solved by the user
by performing certain simple tasks (see the Troubleshoot-
ing paragraph), while some system alarms require that you
contact the Technical Customer Service.
Please keep in mind that any attempt by unauthorised
ꢀ
staff to repair the device automatically voids any form
of warranty.
3ꢀ4ꢀ3 Visualization of alarms on display
In the event of a malfunction, the display shows an
ꢀ
alarm code.
In the event of an alarm, the device still maintains active
ꢀ
functions.
► E1
Room temperature probe AIR/T1 discon-
nected or faulty
None of the modes can be activated.
► E2
Faulty internal fan motor or disconnected
None of the modes can be activated.
► E3
Water temperature probe H2/T2 discon-
nected or failure
None of the modes can be activated.
► CE
Communication error
Errors in the communication between the touchpad
control and the board. None of the modes can be
actived.
The symbol
ant water.
appears to indicate unsuitable radi-
►
►
lampeggiante Incorrect water temperature
In heating mode, the water temperature is below 30
°C.
lampeggiante Incorrect water temperature
In cooling mode, the water temperature is above 20
°C.
3ꢀ4ꢀ4ꢀ ꢀResetꢀfilterꢀcleanerꢀalarm
The flashing
symbol indicates that filter cleaning is
ꢀ
required.
Afterꢀreplacementꢀofꢀfilters,ꢀitꢀisꢀnecessaryꢀtoꢀresetꢀ
theꢀcountꢀofꢀhoursꢀofꢀfilterꢀuse
► press
for about 8 seconds
The
symbol disappears.
11
