Google Nest Learning Thermostat (4th gen) Installation Guide
Key Features and Functionality
This feature allows the user to schedule their thermostat around when they would like to reach a temperature
instead of when they want to start running their system. A user can choose to enable Early On for cooling and
heating setpoints when the home is occupied. They can also choose how long the thermostat can pre-heat the
home overnight. The user can also enable Early On for when they are returning home, which will allow the
thermostat to pre-heat or pre-cool while the user is away to reach the next scheduled temperature preset before
they arrive. This requires Home & Away Routines to be turned on for the thermostat.
Heat Pump Balance optimizes how oſten the thermostat needs to use expensive auxiliary heat. The user will
choose if they would like to prioritize more comfort, more savings, BALANCED or OFF, and Heat Pump Balance
will automatically adjust when AUX comes on by intelligently adjusting the aux lockout temperature.
Heat Pump Balance will also adjust the aux upstage timer, droop, and minimum delay based on the user’s choice
of Comfort vs Savings.
Heat Pump Balance must be disabled during Pro Setup in order to manually set the aux lockout temperature,
aux upstage timer, droop, and minimum delay. The compressor lockout temperature can be changed even if
Heat Pump Balance is enabled.
To use Heat Pump Balance, the thermostat must also be connected to Wi-Fi. If it isn’t, the thermostat won’t be
able to adjust or enforce the aux lockout temp.
If the user has a dual fuel system, they won’t be able to use Heat Pump Balance. Instead, the user will
have to set a breakpoint temperature and changeover timer manually during Pro Setup.
18
