BEOK TGR85-EP Underfloor Heating Thermostat User Guide
| General | Details |
|---|---|
| Name | BEOK TGR85-EP Underfloor Heating Thermostat User Guide |
| Make | BEOK |
| Language | English |
| Filetype | PDF (Download) |
| File size | 2.41 MB |
(1 votes, average: 5.00 out of 5)
Loading...
BEOK Color TFT-LCD Heating Thermostat User Manual
BEOK TDS21WIFI-AC Fan Coil Thermostat Instruction Manual
BEOK TDR89 Zigbee Room Thermostat User Guide
BEOK BOT-R7X Wireless Gas Boiler Heating Thermostat Instruction Manual
BEOK TDS23 Wi-Fi Fan Coil Thermostat Instruction Manual
BEOK TGP53 China Piano Buttons Underfloor Heating Thermostat User Guide
beok TGW60 Thermostat User Guide
BEOK TS4 Series Wi-Fi Touch Screen Thermostat User Manual
BEOK TGP53 Wifi Thermostat User Guide
BEOK TGW60 Glass Screen Thermostat Instruction Manual
BEOK TGR85-EP Manual: Questions and Answers
BEOK TGR85-EP specifications
| Power supply | 100 ~ 240V |
| Maximum load | <16A |
| Sensor | NTC |
| Operating temperature | 0-45°C,5-95%RH(Non-condensing) |
| Dimensions | 86x90x14mm |
| Power consumption | <1W |
How do I install BEOK TGR85-EP into the wall box?
Align the fixator arrow with the display screen and remove the mounting plate. Insert the cassette with a screw. Rotate the fixator 180 degrees to complete installation.
- Turn the fixator so the arrow aligns with the display screen.
- Remove the mounting plate.
- Insert the cassette with a screw.
- Rotate the fixator 180 degrees to finish. User Guide, p. 6
What does the asterisk symbol mean on BEOK TGR85-EP display?
The thermostat is in manual mode, which means programming is not active. User Guide, p. 8
BEOK TGR85-EP compared with other BEOK thermostats
| Specification | BEOK TGR85-EP | BEOK TDS21WIFI-AC | BEOK Color TFT-LCD Heating Thermostat | BEOK TDR89 |
|---|---|---|---|---|
| Power supply | 100 ~ 240V | AC200~240V 50 ~60Hz | 200 ~ 240V 50 ~60Hz | 100 ~ 240V |
| Sensor | NTC | NTC | NTC | NTC |
| Operating temperature | 0-45°C,5-95%RH(Non-condensing) | 0-45℃,5-95RH | 0-45℃,5-95RH | 0-45℃,5-95RH |
| Dimensions | 86x90x14mm | 86x86x13.3mm | 86x86x13.3mm | 86x90x14mm |
| Power consumption | <1W | <0.5W | <0.3W | <1W |
