DAIKIN ONE TOUCH

SMART THERMOSTAT

Homeowner Guide

VIEW FULL SCREEN PDF MANUAL

General	Details
Name	DAIKIN DTST-ONE-ADA-A One Touch Smart Thermostat Installation Guide
Make	Daikin
Language	English
Filetype	PDF (Download)
File size	0.42 MB

Download PDF

(1 votes, average: 5.00 out of 5)

Loading...

• ALL THERMOSTAT INSTRUCTIONS & USER MANUALS
• Daikin

DAIKIN DTST-ONE-ADA-A One Touch Smart Thermostat Installation Guide Overview

Summary of Contents

• Page 1: Daikin One Touch Smart Thermostat Homeowner Guide
• Page 2: Everything you expect in a smart thermostat backed by the world’s leading HVAC manufacturer. Tap the bottom navigation icons to move between the 4 main screens: Getting Started, Home, Schedule, Away, Air Quality. The home screen displays the current temperature, the current system mode, and adjustment slider, as well as icons leading to the top level screens. The schedule screen displays upcoming set-point changes and scheduled times. It also offers access to edit mode, where you can adjust the schedule. The away screen displays energy saving set-points. Energy saving can be invoked manually or automatically when the mobile app recognizes everyone is away. The air quality screen displays indoor air quality levels when a Daikin One home air monitor is connected. Outdoor air quality and weather will be displayed when connected to the internet and thermostat added in the mobile app under home location. Actual screen may vary for different indoor unit models. The Daikin One home air monitor only works with ducted units.
• Page 3: Air quality alert examples Good view example Example of additional details To download the Daikin One home mobile app, scan the QR code or visit Actual screen may vary for different indoor unit models. The Daikin One home air monitor only works with ducted units and is sold separately. Daikin One + smart thermostat homeowner guide
• Page 4: When WiFi is enabled on your Daikin One touch smart thermostat, the Daikin One home mobile app can help you manage and remotely control multiple Daikin One touch smart thermostats in your home. Enabling WiFi adds smart features to your thermostat, including automatic software updates, remote control with mobile app, and voice control capabilities when connected to Amazon Alexa or Google Assistant devices. Geo-fencing detects when you are away from home, reducing energy costs. You can connect the Daikin One touch smart thermostat to WiFi by navigating to the settings menu and selecting WiFi. Ensure the use WiFi box is checked and select your network from the list. To pair the thermostat to the app, navigate to the settings menu and tap Account. Use the code displayed on the thermostat to input into the app. Download the app and create an account from the iOS App Store or Google Play. Add home location after initial account creation. The pair code will expire in 15 minutes, but you can always get a new code if needed.
• Page 5: Connecting Daikin One touch smart thermostat to Amazon Alexa will enable voice command through Alexa. Complete setup on Daikin One touch smart thermostat and Daikin One home mobile app. Login to Alexa account from phone/tablet device. This will successfully link Daikin One touch smart thermostat to Amazon Alexa. Voice commands include setting the thermostat to specific temperatures and adjusting the temperature. Connecting Daikin One touch smart thermostat to Google Home will enable voice command through Google Assistant. Complete setup on Daikin One touch smart thermostat and Daikin One home mobile app. This will successfully link Daikin One touch smart thermostat to Google Home. Voice commands include setting the thermostat to cool or heat and adjusting the temperature. DAIKIN ONE TOUCH SMART THERMOSTAT HOMEOWNER GUIDE.
• Page 6: For systems that have both heating and cooling, you have the ability to choose a mode: auto, cool, heat, or off. How to switch modes: From the Home Screen, simply tap the mode icons located on the left-hand side of the current temperature. From the Settings Menu, access settings from any primary screen by tapping the menu icon. Then select system mode.
• Page 7: With the Daikin One touch smart thermostat, you can create a different schedule for each mode of the thermostat. Your thermostat will have the ability to create a schedule for Heat (only), Cool (only), and Auto mode. To create a schedule, tap on the schedule icon to bring up the schedule menu. Tap the menu icon located in the upper right-hand corner. Select the day you wish to edit by tapping the header in the upper left-hand corner. From the edit screen, tap the “add new event” or “edit event” option located at the bottom of the screen. Edit the name of the event in the Event Label section. Choose the action you want your system to perform in the Event Action section. Be sure to tap save after making your changes.
• Page 8: Copy schedules allow you to easily replicate a day's schedule. To copy a day's schedule, select the day you want to copy. Select copy day on the bottom right footer. Choose which days to copy to, with the copied day greyed out and selected days highlighted. Templates can be used as the basis of a schedule that fits your lifestyle. You can edit the schedule after selecting a template. Any edits in the current schedule will be deleted when loading a template. To create a schedule from a template, tap the menu icon in the upper left corner. Select the settings option, then select schedule, followed by schedule templates. You can view a schedule template by tapping and selecting it from the list.
• Page 9: Customized settings allow you to better suit your comfort needs with the Daikin One touch smart thermostat. Navigate to the settings menu by tapping the menu icon in the top left of the home menu and selecting settings. Tap the Display option to access the preference screen where updates can be made. Choose between a selection of screen savers to be displayed when the thermostat is not being interacted with. Night mode turns off the display and light bar during the selected schedule time when enabled. Access the night mode setting by tapping the brightness option from the display menu. For assistance with setting up your Daikin One touch smart thermostat, contact Daikin support. Select OPTION SEVEN to be connected with the thermostat support team. This document serves as the homeowner guide for the Daikin One touch smart thermostat.
• Page 10: Customized settings continued: Large font option: To enable, open the settings by tapping the menu item in the top left and select “settings.” Navigate to display settings and enable the “use large font” checkbox. Spanish and French language support: To choose a language, open the settings by tapping the menu item in the top left and select “settings.” Navigate to language settings: display > language and select the desired language. Ability to restart thermostat: To restart the thermostat, open the settings by tapping the menu item in the top left and select “settings.” Navigate to system settings: settings > thermostat > restart thermostat and select “restart thermostat.”
• Page 11: Important notes This device complies with Part 15 of the FCC Rules. Operation is subject to two conditions: it may not cause harmful interference and must accept any interference received. This equipment has been tested and found to comply with the limits for a Class B digital device. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy, which may cause harmful interference if not installed and used according to the instructions. If this equipment does cause harmful interference to radio or television reception, the user is encouraged to try to correct the interference. This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s license-exempt RSS(s). Operation is subject to two conditions: the device may not cause interference and must accept any interference that may cause undesired operation. The user is invited to attempt to correct interferences by reorienting or relocating the receiving antenna, increasing separation between the equipment and receiver, or consulting a technician for help.
• Page 12: For additional resources and instructional videos, scan code or visit Daikin One. If you encounter any issues or would like assistance with setting up your Daikin One touch smart thermostat, please contact Daikin support. Before purchasing this appliance, read important information about its estimated annual energy consumption, yearly operating cost, or energy efficiency rating that is available from your retailer. Google, Google Assistant, and all related logos are trademarks of Google, or its affiliates. Amazon, Alexa, and all related logos are trademarks of Amazon.com, Inc. or its affiliates.
